Network · Authentication

How 2plot.ai acts as the Clerk PRIMARY for the whole domain galaxy — the satellite whitelist, the returnTo round trip, and the signup webhook.

---

.. toc::

One account, every app

2plot.ai is the network's Clerk primary instance. Satellite apps (2plot.media, 2plot.xyz, cast.2plot.net, …) run in satellite mode and send visitors here to sign in; after auth the visitor lands back on the exact page that sent them.

The round trip:

1. A satellite deep-links to https://2plot.ai/onboarding?returnTo=<url>. 2. The hub validates returnTo against the satellite whitelist — the same origin list handed to Clerk itself, so there is exactly one place a redirect can be authorized (lib/auth.py, allowed_redirect_origins(); env-overridable via CLERK_ALLOWED_REDIRECT_ORIGINS so a new satellite needs no deploy). 3. The sign-in modal opens with force-redirect URLs pointing back to the validated origin. Invalid or missing returnTo falls through to the hub home — never an open redirect.

.. admonition::Fully optional in dev :icon: tabler:flask :color: yellow

With zero CLERK_* keys in the environment the entire auth layer no-ops: the app runs unauthenticated, owner gates open up, and no network calls are made. Identical code path, zero configuration.

The signup webhook

POST /webhooks/clerk (Svix-verified, fail-closed) receives Clerk events. On user.created the hub provisions the new account's welcome wallet on piratesbargain.com through an HMAC-signed cross-app call — and records the outcome (with a privacy-hashed account reference) to the heartbeat, which is the first sensor of the future ledger-of-record flow.

```python

File: lib/auth.py

"""Optional Clerk authentication gate (dash-clerk-auth, vendored).

The integration is FULLY OPTIONAL: with no CLERK_* keys in the environment (or the package missing) the app runs exactly as before — the package's dash hooks no-op, no script/store is injected, no session machinery or routes register. The single source of truth for "is auth on" lives here; run.py (register/configure), the header avatar chip, and the navbar's owner-gated Analytics reveal all call clerk_enabled().

Env vars (set all three to enable): CLERK_SECRET_KEY sk_... backend SDK key (never exposed to the client) CLERK_PUBLISHABLE_KEY pk_... embedded in the injected <script> CLERK_SIGN_IN_URL https://<app>.clerk.accounts.dev/sign-in REQUIRED in prod (run.py warns loudly when missing): SESSION_SECRET signs the session + __dca_identity cookies — without it the package falls back to a PUBLIC dev default string. CLERK_FRONTEND_API https://<app>.clerk.accounts.dev — origin clerk.browser.js is served from; read by the package straight from the env (not gated here). Dev *.accounts.dev instances can derive it from CLERK_SIGN_IN_URL, but production custom-domain instances CANNOT (their Account Portal doesn't proxy /npm/@clerk/clerk-js) — set it explicitly in prod.

NOTE: read keys at CALL time (not import time) — lib/backend's load_dotenv must have run first, and tests blank env vars per-process. """ import os

The app owner's Clerk account — gates the owner-only surfaces (/traffic and

the navbar Analytics section). Checked CLIENTSIDE against the clerk-auth-store

email for the nav reveal and SERVER-SIDE by lib/security_block's /traffic

gate. Env-overridable per deployment.

OWNER_EMAIL = os.getenv("OWNER_EMAIL", "pipinstallpython@gmail.com")

def clerk_keys(): return (os.getenv("CLERK_SECRET_KEY"), os.getenv("CLERK_PUBLISHABLE_KEY"), os.getenv("CLERK_SIGN_IN_URL"))

def clerk_enabled(): """True only when all three CLERK_* env vars are set AND the package imports.""" if not all(clerk_keys()): return False try: import dash_clerk_auth # noqa: F401 return True except Exception: return False

Satellite origins the PRIMARY (2plot.ai) may redirect a user back to after a

Clerk sign-in. The vendored dash_clerk_auth applies this list to Clerk.load()

on the primary ONLY (gated on !isSatellite) — it is the whitelist that lets a

satellite's signInForceRedirectUrl actually complete. A missing/malformed

entry silently strands the user on the primary's home (the 2026-06 prod bug:

two entries lacked a scheme, and 2plot.net was absent).

_DEFAULT_SATELLITE_ORIGINS = ( "https://2plot.media", "https://www.2plot.media", "https://2plot.net", "https://www.2plot.net", "https://2plot.xyz", "https://www.2plot.xyz", "https://cast.2plot.net", "https://2plot.dev", "https://2plot.me", "https://2plot.world", "https://2plot.shop", # scheduler-docs origin added here once it has a domain )

def allowed_redirect_origins(): """Origins the primary Clerk instance may redirect back to after sign-in.

Env-first via CLERK_ALLOWED_REDIRECT_ORIGINS (comma-separated) so a NEW satellite can be whitelisted without a redeploy; otherwise the galaxy default above. Bare hosts are coerced to https:// (a missing scheme is what silently dropped 2plot.world/2plot.shop in prod) and trailing slashes are stripped (Clerk matches on origin). De-duplicated, order preserved. """ raw = os.getenv("CLERK_ALLOWED_REDIRECT_ORIGINS", "").strip() items = [x.strip() for x in raw.split(",") if x.strip()] if raw \ else list(_DEFAULT_SATELLITE_ORIGINS) seen, out = set(), [] for it in items: if not it.startswith(("http://", "https://")): it = "https://" + it it = it.rstrip("/") if it not in seen: seen.add(it) out.append(it) return out

def identify_request_user(cookies): """Display name of the signed-in Clerk user for THIS request, or None.

Reads the package's signed __dca_identity cookie (minted after a Clerk session verifies) — a cheap itsdangerous signature check, no Clerk roundtrip. Anonymous visitors, auth-off deployments, missing/blank SESSION_SECRET, and stale/tampered cookies all return None. Used by the analytics tracker to stamp authenticated visits for the /traffic log book. """ if not clerk_enabled(): return None secret = os.getenv("SESSION_SECRET") or "" token = (cookies or {}).get("__dca_identity") if not token or not secret: return None try: from dash_clerk_auth._identity_cookie import verify user = verify(token, secret, max_age=7 * 86400) except Exception: return None if not user: return None name = " ".join(x for x in (user.first_name, user.last_name) if x) or user.email or user.user_id return str(name)[:60] ```

:defaultExpanded: false :withExpandedButton: true

Who sees what

| Surface | Audience | | --- | --- | | Home, onboarding, docs, changelog | Everyone | | Activity cockpit (header), /activity/<job> | Signed-in accounts | | /admin/heartbeat, /admin/heartbeat/tasks, /traffic | Owner only |

Owner gating rides the signed identity cookie (no Clerk round trip per request) — see lib/security_block.py.

.. llms_copy::Network · Authentication

---

*Source: /docs/network-auth*
